Concept Latch Lock & Hinge, supply a range of Accuride Ball Bearing heavy duty slides and Rollon telescopic rails for use in heavy duty industrial applications.
Accuride C9308 Heavy Duty Lock-in/Lock-out Ball Bearing Slides Integrated with a lock in/lock out mechanismFinish: Clear electroplate onlyLength: Even lengths of 12” – 36”, 40”, 42”, 48” and 60”Height: 3.00" and side space: 0.75"Max moderate Load rating: 227.3kgQuiet in operation with bumper silencer
Accuride C9301 Heavy Duty Non-locking Ball Bearing SlidesIndustrial strength drawer slides with a full extension mechanism Finish: Bright electro-zinc platingLength: Even lengths of 10” – 36”, 40”, 42”, 44”, 48” and 60” Max moderate load rating: 227.3kgSuitable for a variety of applications including: Computer server storage access, Electronic instrumentation chassis, Large pantry pull-outs and modular storage cabinets
Accuride C7957 Heavy Duty Disconnect SlidesSuitable for use on toolboxes, emergency vehicles, carts,machinery chassis’ for ATM’s and vending machines.Max Load Rating: Side Mount: 159kgsFlat Mount: 68kgsAvailable Lengths: 16, 20, 28, 36 inchesFull ExtensionHanded lever disconnectRollon Telescopic RailsAvailable in seven different models, the Telescopic rail product line features full and partial extension and various cross-sections and intermediate elements in S-shape, double-T or square.High loading with low deflexionRigid intermediate elementsStandardised gauge for holesZero-play running
Models include:ASN- Partial extension consisting of a guide rail and a sliderDS- Full extension consisting of two guide rails made of fixed and movable element and anS-shaped intermediate elementDE- Full extension consisting of two guide rails, which together, combined as double-T profile, form the intermediate element, and two slidersDE- Full extension consisting of two guide rails, which together, combined as double-T profile, form the intermediate element, and two slidersLTF- Full extension consisting of two guide rails as fixed and movable element and an S-shaped intermediate elementDMS- Heavy load telescopic consisting of elements from the ASN series and an extremely rigid double-T profile as intermediate elementDMS- Heavy load telescopic consisting of elements from the ASN series and an extremely rigid double-T profile as intermediate element.
Applications include: Railcars (e.g. maintenance and battery extensions, doors)Construction and machine technology (e.g. housings and doors)Logistics (e.g. extensions for containers or gripper movements)Automotive technologyPackaging machinesBeverage industrySpecial machines
